| Type | L | ré | |||||||
| 6 | 8 | dix | 12 | 13 | 14 | 16 | 20 | ||
| JH090 | 20 | 5,8 | 6.2 | 7.4 | 9.2 | ||||
| 25 | 5,8 | 6.2 | 7,6 | 9.2 | |||||
| 30 | 5,8 | 6.2 | 7,8 | 9.2 | 16,0 | 16,0 | 18,0 | 33,0 | |
| 35 | 5,8 | 6,6 | 7,8 | 9.2 | 16,0 | 16,0 | 18,0 | 33,0 | |
| 40 | 5,8 | 6,6 | 7,8 | 10,0 | 16,0 | 16,0 | 18,0 | 34,0 | |
| 45 | 6.2 | 7,0 | 8,0 | 10,4 | 16,0 | 16,0 | 19,0 | 34,0 | |
| 50 | 6.2 | 7,0 | 8.4 | 11,0 | 16,4 | 16,4 | 19,0 | 35,0 | |
| 55 | 6,6 | 7,8 | 9.4 | 11,6 | 19,0 | 19,0 | 21,6 | 35,0 | |
| 60 | 6,6 | 7,8 | 9.4 | 11,6 | 19,0 | 19,0 | 21,6 | 37,0 | |
| 65 | 7,8 | 8,6 | 10.2 | 12,4 | 21,0 | 21,0 | 23,0 | 38,0 | |
| 70 | 7,8 | 8,6 | 10,4 | 12,8 | 21,0 | 21,0 | 23,0 | 38,0 | |
| 75 | 9,0 | 9,8 | 11,0 | 13.2 | 24,0 | 24,0 | 26,0 | 40,0 | |
| 80 | 9,8 | 10,0 | 11,4 | 13.2 | 24,0 | 24,0 | 26,0 | 40,0 | |
| 90 | 11,4 | 12,0 | 12,6 | 15,2 | 25,0 | 25,0 | 28,0 | 43,0 | |
| 100 | 13,4 | 14,0 | 15,0 | 17,2 | 29,0 | 29,0 | 30,0 | 51,0 | |
| 110 | 15,4 | 16,4 | 17,0 | 19,2 | 33,0 | 33,0 | 34,0 | 51,0 | |
| 120 | 17,4 | 18,4 | 19,0 | 22,0 | 37,0 | 37,0 | 36,0 | 61,0 | |
| 130 | 21,4 | 21,4 | 23,0 | 42,0 | 42,0 | 43,0 | 67,0 | ||
| 140 | 25,4 | 23,4 | 28,0 | 46,0 | 46,0 | 46,0 | 69,0 | ||
| 150 | 29,4 | 15,4 | 32,0 | 54,0 | 54,0 | 54,0 | 85,0 | ||
• Ordre: Type DxL
| ré | Fil |
| ø6 | M4x0,7 |
| O8 | M5x0.8 |
| ø10 | M6x1.0 |
| ø12 | M8 x 1,25 |
| ø14 | M8 x 1,25 |
| ø16 | M8 x 1,25 |
| ø20 | M8 x 1,25 |
| <L30 | L30 ~ 50 | > L50 |
| e = 10 | e = 15 | e = 20 |
